15.1 LAN Settings and Connection (Before Using FTP/Internet Browser/Command Communications)
262
Press the SYSTEM key and bring up the Communications sheet. According to the intended use, make set-
tings as outlined below.
LAN Setup Workflow
(4)
(2)
(1)
(3)
(5)
(6)
(7)
Use the CURSOR keys to move the settings
cursor, and use the F keys to select a setting
item.
See: "8.1.3 Alphanumeric Input" ( p.121)
For details on each setting, see "Setting Items" ( p.261).
About the network
For IP address information and other details about the net-
work you are using, contact your network administrator.
Purpose
When Connecting to an Existing Network
When Configuring a New Net-
work with a PC and This In-
strument
Obtain IP address automatically
and connect to network
Use specified IP address and
connect to network
To assign a name to the instrument, make a setting for (1) [Host Name]
Settings within same
network
(2) [Use DHCP]: On (2) [Use DHCP]: Off
(2) [Use DHCP]: Off
(3) Set [IP Address] for this
instrument
(3) Set [IP Address] for this
instrument
(4) Set [Subnet Mask] (4) Set [Subnet Mask]
Settings for connecting
to other network
(Using gateway)
(5) [Gateway]: On
(5) Set [Gateway]: Off
(6) Set gateway [IP Address]
Connect
(7) Execute [Reset] (7) Execute [Reset]
Connect with straight-through cable
See: "15.1.2"( p.263)
Connect with crossover cable
See:"15.1.2"( p.263)
(Set automatically)
