10.1 Numerical Calculation Workflow
175
Chapter 10 Numerical Calculation Functions
10
Applying Calculations to Existing Data
(Load the Data) (To load measurement data from storage media for calcu-
lation)
( p.77)
Make Calculation Settings
Make calculation settings on the Numerical Calculation
sheet ([Num Calc] sheet)
(
p.176)
When judging based on calculation results: (
p.180)
Execute Calculation Select [Exec] to execute calculations.
(To interrupt calculations, press the STOP key)
Display Calculation Results Results are displayed on the Waveform screen. ( p.179)
(Calculation Judgments) (only if judgments are enabled)
(Print or Save) Print or save calculation results as occasion demands.
• Print: PRINT key
• Save: SAVE key
When [Print Calc Result] (
p.184) or [Save Calc Result]
(
p.183) is set to [On], results are automatically printed or
saved.
When specifying a waveform range for calculation:
Before executing a calculation, specify the calculation range using the A/B
cursors (div or Trace cursors) on the Waveform screen. Set the calculation
range on the [Num Calc] sheet to [A-B Wave].
• Range cursors cannot be used to specify the range.
• When one cursor is used, the calculation range is from the cursor to the
end of the data.
See: "7.2 Specifying a Waveform Range (A/B Cursor)" ( p.105)
"10.2 Settings for Numerical Value Calculation" (
p.176)
To Next Page
