13.9 FFT Analysis Modes

239

Chapter 13 FFT Function

Normal display

X axis: Log

Y axis: Log-Mag

Normal display

X axis: Log

Y axis: Lin-Real

Normal display

X axis: Log

Y axis: Lin-Imag

Lin‑Imag

If the cursor is displayed, the total harmonic distortion (THD), which sets the fun-

damental wave as the cursor position, is displayed. When 2 cursors appear, the

one with the low frequency becomes the fundamental. When results cannot be

obtained, [---%] is displayed.
