Hioki 8847 - 16.2 External I;O; 16.2.1 External Input (START;EXT.IN1) (STOP;EXT.IN2) (PRINT;EXT.IN3)

15.6 USB Settings and Connection (Before Command Communications)
279
12
Chapter 15 Connection to a Computer
15
After the "Found New Hardware" window appears, the [Found New Hardware
Wizard] dialog box will appear.
3. Click [No:not this time] and click the [Next] button.
4. Select [Install from a list or specific location] and then click [Next].
Depending on the version of Windows XP used, instead of displaying this dialog
box the PC might go directly to the dialog box in Step "6." instead.
USB cable
8847 Memory HiCorder
PC
If after installing the driver you connect the instrument to the personal PC using a
different USB port, the "Found New Hardware" window will appear again and the
Found New Hardware Wizard will start up. Use this wizard to install the driver
again for this port.
(1) Click
(2) Click
(1) Click
(2) Click
