17.5 Built-In Functions
303
Chapter 17 Specifications
17
Position Display (VIEW) Functions
Others
Display function All types of positions, memory division blocks (only when using memory division), waveform
search results, past waveform history (when memory division is OFF, depends on record length)
Relative position display Displays the relative position of the currently displayed waveform within the overall recording
length, and locations of cursors and trigger events
Block display Block usage status (when memory division is ON) or past waveform history status (when memory
division is OFF)
Displayed block position
Jump function Jump to trigger position/cursor position, jump to desired block, jump to past waveform (when mem-
ory division is OFF), and jump to waveform search position
On-line help function Pressing the HELP key displays help for the item at the currently selected (blinking) item (the
whole screen is not used)
Basic help (when making settings, displays a brief description of the selected (blinking) item along
the bottom of the screen)
Grid types Display: Off, normal or normal (dark)
Printouts: Off, normal, fine, normal (dark) or fine (dark)
Comment display Comments are displayed with channel numbers on the screen and in printouts (channel markers)
Time scale display Time (seconds, base-60), divisions, Date, sample number (screen and printouts)
Variable auto-compensation Included
Start backup function Included
Backlight Saver Off, or 1 to 30 min
Display color Color 1 to 3, or user-defined
Beep sound Off, warnings, or warnings and operations
Language Japanese/English/Korean
Start key function Press once, twice or hold for two seconds
Stop key function Press once, or twice
External I/O terminals Trigger I/O terminals (EXT_TRIG, TRIG_OUT), External sampling input terminal (EXT_SAMP)
Remote control input terminal (START, STOP, PRINT),* Judgment output terminals (GO/NG)
*:User selectable
Remote control Select external I/O terminals for remote control (Start, Stop, Abort, Start&Stop, Pen_Up,
Pen_Down, Print, Save)
Internal status output For the GO/NG terminals, select (Error, Busy, Awaiting Trigger or Numerical Judgment)
Probe calibration output Output from NG/EXT OUT2 terminal
Keylock function Included
Recording printout content Waveform
Printout magnification Prints waveforms magnified or compressed on the time axis, regardless of Waveform screen dis-
play
Print size Standard (A4) or Reduced (A6)
Print density 5 levels
Print Speed Fast/Coarse, Normal or Slow/Fine
Upper/lower limit printing Off / On
Zero-position comments Off/On But not overlaid
Text comment printing Load text file and print at printing start time.
Counter printing Off, date or counter name and count value
GUI partial printing/saving Off / On
List Prints a list of settings
Gauge Prints gauges for measurement channels (the same range is displayed on the same gauge)
Gauges can be displayed
Waveform backup function None
Auto setup function When switched on, settings are automatically loaded from a file on the CF card, hard disk or inter-
nal memory.
Auto measurement function Automatically selects the optimal timebase and voltage range for the input waveform
Backlight brightness Selectable from 3 levels
Time setting Included
Initialization System reset, or clear waveform only
Self-Test function ROM/RAM, Printer, Display, Key
