2.2 Connecting Cords

See p.21 for details for how to connect to a BNC terminal.

Applicable Input Modules

• 8970 Freq Unit

Use to connect: Connection cords

• 9197 Connection Cord

(Maximum input voltage: 500 V)

Large alligator clip type

• L9198 Connection Cord

Maximum input voltage: 300 V)

Small alligator clip type

• L9217 Connection Cord

(Maximum input voltage: 300 V)

For measuring BNC output

If the voltage to be measured exceeds

the maximum input rating of the input

module being used:

• 9322 Differential Probe*

Example: 9322 Differen-

tial Probe

Measuring frequency, number of rotations and Count

Connect to the BNC jack on an input mod-

ule.

* A power cord option or AC adapter may

be required.
