Appendix 2 Reference
A7
Appendix
(d: days/ h: hours/ min: minutes/ s: seconds)
Memory Function
Timebase
(Time/div)
Sampling
Speed
Channels used
Maximum Recording Length
16 channels 8 channels 4 channels 2 channels
40,000 div 80,000 div 160,000 div 320,000 div
5 μs 50 ns 200 ms 400 ms 800 ms 1.6 s
10 μs 100 ns 400 ms 800 ms 1.6 s 3.2 s
20 μs 200 ns 800 ms 1.6 s 3.2 s 6.4 s
50 μs 500 ns 2 s 4 s 8 s 16 s
100 μs 1 μs 4 s 8 s 16 s 32 s
200 μs 2 μs 8 s 16 s 32 s 1 min 4 s
500 μs 5 μs 20 s 40 s 1 min 20 s 2 min 40 s
1 ms 10 μs 40 s 1 min 20 s 2 min 40 s 5 min 20 s
2 ms 20 μs 1 min 20 s 2 min 40 s 5 min 20 s 10 min 40 s
5 ms 50 μs 3 min 20 s 6 min 40 s 13 min 20 s 26 min 40 s
10 ms 100 μs 6 min 40 s 13 min 20 s 26 min 40 s 53 min 20 s
20 ms 200 μs 13 min 20 s 26 min 40 s 53 min 20 s 1h 46 min 40 s
50 ms 500 μs 33 min 20 s 1h 6 min 40 s 2h 13 min 20 s 4h 26 min 40 s
100 ms 1 ms 1 h 6 min 40 s 2 h 13 min 20 s 4 h 26 min 40 s 8 h 53 min 20 s
200 ms 2 ms 2 h 13 min 20 s 4 h 26 min 40 s 8 h 53 min 20 s 17 h 46 min 40 s
500 ms 5 ms 5 h 33 min 20 s 11 h 6 min 40 s 22 h 13 min 20 s 1 d 20 h 26 min 40 s
1 s 10 ms 11 h 6 min 40 s 22 h 13 min 20 s 1 d 20 h 26 min 40 s 3 d 16 h 53 min 20 s
2 s 20 ms 22 h 13 min 20 s 1 d 20 h 26 min 40 s 3 d 16 h 53 min 20 s 7 d 9 h 46 min 40 s
5 s 50 ms 2 d 7 h 33 min 20 s 4 d 15 h 6 min 40 s 9 d 6 h 13 min 20 s 18 d 12 h 26 min 40 s
10 s 100 ms 4 d 15 h 6 min 40 s 9 d 6 h 13 min 20 s 18 d 12 h 26 min 40 s 37 d 0 h 53 min 20 s
30 s 300 ms 13 d 21 h 20 min 0 s 27 d 18 h 40 min 0 s 55 d 13 h 20 min 0 s 111 d 2 h 40 min 0 s
50 s 500 ms 23 d 3 h 33 min 20 s 46 d 7 h 6 min 40 s 92 d 14 h 13 min 20 s 185 d 4 h 26 min 40 s
1 min 600 ms 27 d 18 h 40 min 0 s 55 d 13 h 20 min 0 s 111 d 2 h 40 min 0 s 222 d 5 h 20 min 0 s
100 s 1 s 46 d 7 h 6 min 40 s 92 d 14 h 13 min 20 s 185 d 4 h 26 min 40 s 370 d 08 h 53 min 20 s
2 min 1.2 s 55 d 13 h 20 min 0 s 111 d 2 h 40 min 0 s 222 d 5 h 20 min 0 s
5 min 3 s 138 d 21 h 20 min 0 s 277 d 18 h 40 min 0 s
