SYSTem Subsystem
SYSTem:PRESet
11-30 HP E4418B/E4419B Programming Guide
CAL:ECON:STAT ON TTL zero/cal inputs disabled
CAL:RCAL not affected zero/cal lockout
CAL:RCF 100.0% Reference calibration factor
CAL:ZERO:AUTO OFF Automatic zeroing disabled
DISP:CONT not affected Display contrast
DISP:ENAB ON Display enabled
DISP[:WIND[1|2]]:FORM HP E4418B:
Upper - digital
Lower - analog
HP E4419B
Upper - digital
Lower - digital
Display format
DISP[:WIND[1|2]]:MET:LOW -70.000 dBm Analog meter lower limit
DISP[:WIND[1|2]]:MET:UPP +20.000 dBm Analog meter upper limit
DISP[:WIND[1|2]]:RES 3 Window resolution
DISP[:WIND[1|2]]:SEL upper window Window selected
DISP[:WIND[1|2]][:STAT] ON Both windows enabled on display
FORM[:READ]:BORD normal Binary order
FORM[:READ][:DATA] ascii Data format
INIT:CONT *RST: OFF
SYS:PRES ON
Power Meter in “idle” state
Power Meter in “wait-for-trigger” state
MEM:TABL:SEL not affected Active sensor calibration table
OUTP:ROSC OFF 50 MHz reference disabled
OUTP:TTL[1|2]:ACT
LOW
TTL output active low
OUTP:TTL[1|2]:FEED “CALC:LIM:UPP” TTL output represents upper limit fail
OUTP:TTL[1|2]:STAT OFF TTL output is disabled
SENS:AVER:COUN 4 Filter length
SENS:AVER:COUN:AUTO ON Auto-filtering enabled
SENS:AVER:STAT ON Averaging enabled
SENS:CORR:CSET:SEL not affected Selected sensor calibration table
SENS:CORR:CSET:STAT not affected Sensor calibration table disabled
SENS:CORR:DCYC|GAIN3 1.000% Duty cycle factor
SENS:CORR:DCYC|GAIN3:STAT OFF Duty cycle correction disabled
SENS:CORR:CFAC|GAIN1 100.0% Calibration factor
SENS:CORR:GAIN2 0.000 dB External gain
SENS:CORR:GAIN2:STAT OFF External gain correction disabled
Command
Setting Comments
