HPE FlexNetwork MSR Series User Manual

51
Configuring a CE1/PRI interface in CE1 mode
Figure 33 Configuring a CE1/PRI interface in CE1 mode
Table 33 Configuration items (in CE1 mode)
Item Description
WAN Interface Displays the name of the CE1/PRI interface to be configured.
Interface Status
Display and set the interface status:
• Connected—Indicating that the current interface is up and connected, click
Disable to shut down the interface.
• Not connected—Indicating that the current interface is up but not connected,
click Disable to shut down the interface.
• Administratively Down—Indicating that the current interface is shut down by
a network administrator, click Enable to bring up the interface.
Work Mode: CE1 Select CE1 as the operating mode.
Operation
Add or remove timeslots:
• create—Adds timeslots to form a channel set.
• delete—Removes timeslots from a channel set.
Serial Specify the serial interface number of the channel set.
Timeslot-List Set the timeslots to add or remove.
User Name Configure the username for authentication.
Password
Displays whether a password is configured for authentication.
If the field displays null, no password is configured for authentication.
New Password Set or modify the password for authentication.
TCP-MSS Configure the TCP MSS on the interface.
