328
Figure 720 E1 parameters configuration page (1)
Table 266 Configuration items
Item Description
Physical Parameters Configuration
Working Mode
Configure the working mode of the E1 interface:
• None—Remove the existing bundle.
• PRI trunk signaling—Bundle timeslots on an E1 interface into a PRI group.
By default, no PRI group is created.
Bound Timeslot
Number
Specify the timeslots to be bundled.
Frame Check Mode
• CRC4—Perform cyclic redundancy check (CRC).
• NO_CRC4—Do not perform CRC.
Line Coding
• HDB3—The line coding format is high-density bipolar 3 (HDB3).
• AMI—The line coding format is alternate mark inversion (AMI).
