HPE FlexNetwork MSR Series User Manual

339
Item Description
Ignore the Sending-Complete
Information Element in Setup
Messages
• Enable for outgoing direction—Configure the ISDN protocol to send
Setup messages without the Sending-Complete Information Element
when placing a call.
• Enable for incoming direction—Configure the ISDN protocol to
ignore the Sending-Complete Information Element in Setup messages
when receiving a call.
• Enable for bidirectional directions—Configure the ISDN protocol to
ignore the Sending-Complete Information Element in Setup messages
when receiving a call, and to send Setup messages without the
Sending-Complete Information Element when placing a call.
• Disable (default)—Configure the ISDN not to ignore the
Sending-Complete Information Element in Setup messages. When
the data exchange performed between the device and an ISDN
switch, for an incoming call, the device checks the received Setup
messages for the Sending-Complete Information Element to
determine whether or not the number is received completely. If a
Setup message does contain the Sending-Complete Information
Element, the number is not received completely. For outgoing calls, a
Setup message containing the Sending-Complete Information
Element indicates that the number is sent completely.
Q.921 Permanent Link
Configure the Q.921 permanent link function:
• Enable—The BRI interface sets up a data link connection
automatically and maintains the connection even when no calls are
received from the network layer. If the two-tei mode is also enabled on
the interface, two such connections are present.
• Disable—Disable the Q.921 permanent link function on the BRI
interface.
This parameter is available only when the
User Side Mode
option in the
ISDN Working Mode
area is selected.
ISDN two-tei
• Enable—Each call on the BRI interface uses a different EI.
• Disable—All calls on all the B channels on the BRI interface use one
TEI value.
ISDN Link Mode
• Point-to-Multipoint—A BRI interface operating on the network side
can have multiple end devices attached to it.
• Point-to-Point—Configure the BRI interface operates in
point-to-point mode.
BSV Permanent Active State
at the Physical Layer
• Enable—Specify an ISDN BRI interface to be in the permanent active
state at the physical layer.
• Disable—The BRI interfaces operating on the network side are not in
the permanent active state at the physical layer.
This parameter is available only when the
Network Side Mode
option in
the
ISDN Working Mode
area is selected.
BSV Remote Powering
• Enable—Enable remote powering on an ISDN BRI interface.
• Disable—Disable remote powering on an ISDN BRI interface.
This parameter is available only when the
Network Side Mode
option in
the
ISDN Working Mode
area is selected.
ISDN Sliding Window Size Set the sliding window size on an ISDN BRI interface.
ISDN T302 Timer Duration Configure the duration of the ISDN protocol Layer 3 timer T302.
