HPE FlexNetwork MSR Series

To Next Page

To Previous Page

Figure 37 VLAN interface setup page

Table 37 Configuration items

Item Description

VLAN ID Select the ID of the VLAN interface you want to configure.

IP Address

Subnet Mask

Set the VLAN interface's IP address and subnet mask.
