4. Operation of SEP Related Controllers
240
No.21 (Zone boundary 1 + side)
Set + side of the area in which the zone signal (ZONE 1) is turned ON.
No.22 (Zone boundary 1 - side)
Set - side of the area in which the zone signal (ZONE 1) is turned ON.
No.23 (Zone boundary 2 + side)
Set + side of the area in which the zone signal (ZONE 2) is turned ON.
No.24 (Zone boundary 2 - side)
Set - side of the area in which the zone signal (ZONE 2) is turned ON.
No.25 (PIO inching distance)
Set an inching distance for the inching entry command from PLC.
No.26 (Target value for total number of movements)
If the total number of movement exceeds the setting of this parameter, an alarm is generated
to inform.
No.27 (Target value for total travelled distance)
If the total travelled distance exceeds the setting of this parameter, an alarm is generated to
inform.
No.28 (High output setting)
Set whether to use the high output function. However, the actuator complying with high
power
(Note 1)
has to be connected.
(Note 1) Actuator complying with high power: RCP 4 and RCP 5 series (except for high thrust
types)
No.29 (BU Speed Loop Proportional Gain)
When setting the high output setting parameter valid, this parameter is effective for the speed
loop proportional gain.
No.30 (BU Speed Loop Integral Gain)
When setting the high output setting parameter valid, this parameter is effective for the speed
loop integral gain.
No.31 (Overload Level Ratio)
If it exceeds the rated current ratio set, the overload alarm (message level) is turned ON.
No.32 (Minor Failure Alarm Output Selection)
With setting 0, if the rated current ratio exceeds the value set in the overload level ratio
parameter, ALM is output.
With setting 1, ALM is output by even message level alarms, such as the maintenance
information error, in addition to the result of the overload level ratio.
