5. Operation of MEC Related Controllers
287
No. Operation Screen Remarks
7 Touch [Teach].
8 Touch [Yes].
9 Touch [Menu].
10 “80.00” is shown in the
position field.
This confirms that the position
data has been loaded.
Touch [Menu] to return to the
position setting screen.
11 Touch [Menu]. Touch [Menu] to return to the
position setting screen.
12 Touch [Menu] to return to the
MEC menu screen.
