3. Operation of CON Related Controllers
58
Servo Press Type Control Signal 1 Details
Bits Symbol Name
00 APRC In Approaching Operation
01 SERC In Searching Operation
02 PRSS In Pressurizing Operation
03 PSTP Pressurizing in Stop
04 DCMP In Depressurizing Operation
05 RTRN In Return Operation
06 WAIT Program in Standby
07 - (Reserved)
08 - (Reserved)
09 - (Reserved)
10 PJOK Position (Distance) Judgment Passed
11 PJNG Position (Distance) Judgment Failure
12 LJOK Load Judgment Passed
13 LJNG Load Judgment Failure
14 JDOK Total Judgment Passed
15 JDNG Total Judgment Failure
Servo Press Type Control Signal 2 Details
Bits Symbol Name
00 SV Servo-on Status
01 HEND Home-Return Complete
02 CEMD Loadcell Calibration Complete
03 RMDS Operation Mode Status
04 PEND Positioning Completion
05 - (Reserved)
06 ZONE1 ZONE 1
07 ZONE2 ZONE 2
08 PCMP Program Completed in Normal Condition
09 PRUN Program Executed
10 PORG Program Home Position
11 MPHM In Move to Program Home Position
12 PALM Program Alarm
13 ALML Light Malfunction Alarm
14 ALM Alarm
15 EMSG Emergency Stop
To Next Page
