7. Press the «Right» arrow.
The cursor jumps to the next position of the message text.
8. Enter the remaining characters of the message text in the same manner.
9. Press «Enter».
The message text has been entered.
10. Press «Enter».
The setting is applied.
8.11.3.3 Selecting and activating measured value
1. Press the «DOWN» key.
2. Press «Enter».
The display for the currently set measured value flashes.
3. Use «Up» or «Down» to select the measured value.
4. Press «Enter».
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.2.1.1 AnMod_p_1
Menu
AnMod_p_1 Title 0.0 psi
Message text
pNloc ☐
Selected analog measured value
·········
SP: 116psi ¦ SD: −7.3psi
Switching point (SP) and switching differential (SD)
td: 0s
Time delay (td)
·········
5. Press the «Right» arrow.
6. Press «Enter».
The check box assigned to the input flashes.
7. Press the «Up» key.
The check box is activated.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.2.1.1 AnMod_p_1
Menu
AnMod_p_1 Title 0.0 psi
Message text
pNloc ☑
Selected analog measured value, activated
·········
SP: 116psi ¦ SD: −7.3psi
Switching point (SP) and switching differential (SD)
td: 0s
Time delay (td)
·········
8. Press «Enter».
The measured value is assigned and activated.
8 Initial Start-up
8.11 Setting input and output signals
160
User Manual Controller
