Keysight N9915-90020 User’s Guide 431
5G Rapid Prototype Phased Array Antenna – Option 360
About Phased Array Antenna Measurements
CW vs. Pulsed RF Measurements
Figure 14-8 Bore-Site Measurement with CW RF (Dwell Time=10 ms, Max Hold=OFF)
IMPORTANT! For pulsed RF measurements, increasing the Dwell Time is
recommended for faster throughput and accurate signal capture in a single
sweep.
