Keysight N9915-90020 User’s Guide 439
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
b. Record Save/Recall (If you have previously stored data
recordings.)
—
Save Log File or
—
Recall Log File or
—
User Folder Def System (Default = Default) or
—
File Type (Default = KML) CVS or DREC (DREC is
only available with Option 360 only)
— Then Auto Save OFF ON (Default = OFF).
c. Indoor Map Data Logging - then Record Indoor Data or
Recall Indoor Log File.
— Then choose Navigate OFF ON, Data Selection,
Zoom, Pan, Record Data, More
9. Press Back to return to previous menu.
10. If recording, then:
—
Pause Resume Temporarily halts recording until pressed again. The
incoming trace continues to sweep. Press again to continue
recording.
—
Stop Immediately
— The Save the log file menu opens. Edit the filename and
press Done to exit menu. See Settings below and
“To
change Data Logging Configuration settings:” on
page 456
.
— To change your file settings or measurement interval.
Learn more, refer to “To change Data Logging
Configuration settings:” on page 456
.
— (Press Record to begin a new recording.)
Spectrum information is not recorded. Only the TableChart data are saved.
See
“How to Record a Data Log” on page 456.
Data Log-Play files are saved to:
— If File Folder is set to Default then Data Log-Play files are save-recalled
to: "[CurrentDevice]\RecordPlayback\PAA"
— If File Folders are set to System, then Data Log-Play files are
save-recalled to: "CurrentDevice\<UserSelectedFolder>\
Learn more about file settings, refer to
Chapter 33, “File Management.”.
