— Clear Graphics If applicable, this clears the current displayed PNG
graphic from the screen.
7. User markers to identify azimuth and elevations settings:
Select Marker –choose:
— Marker 1 2 3 4 5 6 – You can set up to six markers. The OFF, Normal,
Delta, or Peak softkey is black to indicate the current setting of each
marker.
— Normal displays a marker.
— Delta displays a marker relative to another active marker.
—
Peak displays a marker on the peak point of the displayed trace.
—
More – choose.
— Marker Trace – You can set up to four traces.
—
Marker Table – Enable or disable the marker table that displays the
current markers and their values.
Learn more about markers. Refer to the Chapter 30, “Data Analysis
Features.”
.
See also
Figure 14-5 on page 428.
8. Enable the Data Logging settings:
— Press Trace 6
> Data Logging then
— Record (Outdoor Logging) or
— Play (If you have previously stored data recordings.) or
— To set Data Logging—choose:
a. Record Settings (Outdoor Mapping only) – then choose:
— Optional: Then Meas Interval > ON
— Then Interval Type > choose Time or Distance.
— Then, if applicable
Time Interval enter time
interval in seconds.
Or
— Then, if applicable Distance Interval enter
distance interval in miters.
— Then
Back
If after making the setting changes in the steps below, no data is
displayed, refer to
“Troubleshooting” on page 459.
