452 Keysight N9915-90020 User’s Guide
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
— DCREC (Option 360 only)
— Then Save Log File.
or
— Then Recall Log File.
—
Auto Save (default = OFF)
— Then
Back
c. Optional: Press Indoor Map Data Logging then
— Record Indoor Data or Recall Indoor Log File. Learn more,
refer to
“How to Use Data Logging/Playback (Option 360)” on
page 454
, Chapter 16 Mapping and “Option 352 Indoor Maps
Setup Procedure” on page 491
.
— Then choose from
Navigate OFF ON, Data Selection, Zoom,
Pan, Record Data, More
— Learn more, refer to Chapter 16 Mapping and “Setting up
Data Logging” on page 503
.
2. Press
Back to return to previous menu.
3. Outdoor Mapping: Press
Record to begin a new recording and then
— Pause Resume Temporarily halts recording until pressed again. The
incoming trace continues to sweep. Press again to continue
recording.
—
Stop Immediately stops recording and a “Save the Log File” menu
opens to rename and save your data log file.
— (Press Record to begin a new recording.)
— Then
Maps To enable map view and related features (e.g., Data
Selection, Red/Blue Limits, Labels & Icons, Zoom).
—
View Map OFF ON Displays the current GPS location.
Three file types are supported for save or recall log results:
— KML file format
——Files stored in this format can be imported into 3rd
party applications like Google Earth or Google Maps.
— CSV file format. Files stored into this format can be imported into
spreadsheet applications.
— DREC file format. This file type is a binary file. File contains
recorded state and trace data, with GPS time and locations
stamps if enabled. Available with Option 360 only.
