Keysight N9915-90020 User’s Guide 453
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
— Data Selection Opens a softkey menu to set the active
data channel, sort type, and sort order. See also previous
steps
10 in “How to Set Up Phased Array Antenna
Settings” on page 433
.
—
Red/Blue Limits Opens a softkey menu to assign power
values to the red (high power limits) and blue (low power
limits) heat map display limits (defaults: Red Limit =
–20 dBm, Blue limit = –90 dBm).
— Labels & Icons Opens a softkey menu to enable/disable
map data point labels and icon types.
—
Save Image (PNG) Saves the current displayed map to a
*.png file (default filename is “MapImageFile”).
4. When done press
Stop. The log file is automatically saved to the defined
Device Type and File Type.
Else, edit the User Folder and File Type, under Record Save/Recall where
the file results will be stored.
5. Press Back
Playing a Data Log and Viewing the Data
To play the log results:
1. Press Record Save/Recall > Recall Log File
And, use the Use the RPG or the arrow keys to highlight the file to be
played.
2. Press
Recall File > Back > Play
3. Press Stop to exit the log playing.
To pause the log play:
Labels OFF ON
Enables/Disables map data point labels. When enabled,
a label is displayed for every map data point (e.g., “Data
1”). When disabled, labels are not displayed for the map
data points.
Icons
Flag Point Line
Sets the type of icon that is used to display a map’s data
points (default = Flag).
Learn more about file settings, refer to the Chapter 33, “File Management”.
