Keysight N9915-90020 User’s Guide 487

Indoor and Outdoor Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option

233), and GPS Receiver (Option 307))

Importing a .zip File to the FieldFox

Figure 16-11 Example of Maps Folder Containing Imported Maps *.zip Files to the

FieldFox’s InternalSD\UserData\Maps Folder
