500 Keysight N9915-90020 User’s Guide
Indoor and Outdoor Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option
233), and GPS Receiver (Option 307))
How to Set Up Mapping Settings
——List files (*.csv and *.kml) are save-recalled to:
"[CurrentDevice]:\RecordPlayback\CS\"
——Record-Play files are save-recalled to:
"[CurrentDevice]:\RecordPlayback\CS\"
Or
—
System – Sets the User Folder to the user defined system
folder path/name:
——List files are save to-from
"CurrentDevice\<UserSelectedFolder>\"
——Record-Play files are save-recalled to:
"CurrentDevice\<UserSelectedFolder>\"
Refer to “File Management” on page 817.
— Then File Type
— KML or
— CSV (default)
— Then
Save Log File.
or
— Then
Recall Log File.
— Optional
Auto Save ON (default = OFF). To avoid loss of data, if
power loss occurs.
— Then Back
8. Set up the outdoor mapping:
a. Press Trace 6 > Data Logging
b. Then press
Record
c. When done, Stop
d. Save results to KML file.
9. View KML with map tools.
— On the FieldFox, see the data results overlaying OpenStreetMaps’
pictures.
Or use Google Maps or similar to view your maps on your PC. Refer
to
“Import and Play back KML Files into 3rd Party Software
(Example: Google Earth with Animation Tool)” on page 501
.
