148 Keysight E4980A/AL Precision LCR Meter
Configuring Measurement Conditions (Display and Function Related Settings)
LIST SWEEP SETUP Page
4-
Step 8. Using the cursor keys, select the LOW field.
Step 9. Enter the lower limit value.
Step 10. Using the cursor keys, select the HIGH field.
Step 11. Enter the upper limit value.
Step 12. Repeat Step 4 to Step 11.
To clear the entire table:
Step 1. Press [Meas Setup].
Step 2. Press the LIMIT TABLE softkey.
Step 3. Using the cursor keys, select the No. field.
Step 4. Press the CLEAR TABLE softkey.
Settings of upper and lower limit value vary depending on the option
The lower limit value/upper limit value of the sweep parameters you can set
vary as follows depending on the option installed in the E4980A/AL. The
options are Power/DC Bias Enhance (option 001) and Bias Current Interface
(option 002).
B Uses the measurement function’s secondary parameter as the limit
parameter.
- Turns OFF the sweep point limit feature.
Softkey Description
Option 001 Installed Installed Not installed Not installed
Option 002 Installed Not installed Installed Not installed
FREQ[Hz] 20 - 2M 20 - 2M 20 - 2M 20 - 2M
LEVEL[V] 0 - 20 0 - 20 0 - 2 0 - 2
LEVEL[A] 0 - 100 m 0 - 100 m 0 - 20 m 0 - 20 m
BIAS[V] -40 - 40 -40 - 40 0 - 2 0 - 2
BIAS[A] -100 m - 40 -100 m - 100m 0 - 40
---
1
DC SRC[V] -10 - 10 -10 - 10
---
1
---
1
IMP RNG
2
0.1 - 100 k 0.1 - 100 k 1 - 100 k 1 - 100 k
1. An error message “DC bias opt not installed” appears.
2. GPIB command is available.
