186
017: Harm.Chorus
(Stereo Harmonic Chorus)
This effect applies chorus only to higher frequencies.
This can be used to app
ly a chorus effect to a bass
soundwithoutmakingthesoundthinner.Youcanalso
usethischorusblockwithfeedbackasaflanger.
g: High/Low Split Point
This parameter sets the frequency that splits the high and low
range. Only the high range will be sent to the chorus block.
h: Feedback
Sets the feedback amount of the chorus block. Increasing the
fee
dback will allow you to use the effect as a flanger.
018: MTap Ch/Dly
(Multitap Chorus/Delay)
ThiseffecthasfourchorusblockswithadifferentLFO
phase.
You can create a complex stereo image by set‐
ting each block’s delay time, depth, ou
tput level, and
pan individually. You can also fix some of the chorus
blockstocombinethechorusanddelayeffects.
a
LFO Waveform
Selects LFO Waveform
Triangle, Sine
b
LFO Phase [degree] –180...+180
Sets the LFO phase difference between the left and right Fx:010
c
LFO Frequency [Hz] 0.02...20.00Hz
Sets the LFO speed Fx:009,
Src
Selects the modulation source of LFO speed
Off...Tempo
Amt –20.00...+20.00Hz
Sets the modulation amount of LFO speed
d
BPM/MIDI Sync Off, On
Switches between using the frequency of the LFO speed and using the
tempo and notes Fx:009,
BPM
Selects MIDI Clock and assigns tempo
MIDI, 40...240
Fx:009
Base Note
Selects the type of notes that specify the LFO speed Fx:009
Times x1...x16
Sets the number of notes that specify the LFO speed Fx:009
e
Pre Delay [msec]
Sets the delay time from the original sound
0.0...50.0msec
f
Depth
Sets the depth of LFO modulation
0...100
Src Off...Tempo
Selects the modulation source of the LFO modulation depth
Amt –100...+100
Sets the modulation amount of the LFO modulation depth
g
High/Low Split Point 1...100
Sets the frequency split point between the low and high range
h
Feedback
Sets the feed back amount of the chorus block
–100...+100
High Damp [%] 0...100%
Sets the high range damping amount of the chorus block
i
Low Level
Sets the low range output level
0...100
High Level
Sets the high range (chorus) output level
0...100
j
Wet/Dry Dry, 1:99...99:1, Wet
Table , “Sets the balance between the effect and dry sounds,” on page 175
Src Off...Tempo
Table , “Selects the modulation source of the effect balance,” on page 175
Amt
Table , “Sets the modulation amount of the effect bal-
ance,” on page 175
–100...+100
Left
Right
Feedback
LFO Phase
LFO: Tri / Sine
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
Low Level
Low Level
High Level
High Level
High/Low Split Point
High Damp
Chorus/Flanger
Chorus/Flanger
a
LFO Frequency [Hz]
Sets the LFO speed
0.02...13.00Hz
b
Tap1(000) [msec]
Sets the Tap1 (LFO phase=0 degrees) delay time
0...570msec
Depth
Sets the Tap1 chorus depth
0...30
Level
Sets the Tap1 output level
0...30
Pan L6...L1, C, R1...R6
Sets the Tap1 stereo image
c
Tap2(180) [msec] 0...570msec
Sets the Tap2 (LFO phase=180 degrees) delay time
Depth
Sets the Tap2 chorus depth
0...30
Level
Sets the Tap2 output level
0...30
Pan L6...L1, C, R1...R6
Sets the Tap2 stereo image
d
Tap3(090) [msec] 0...570msec
Sets the Tap3 (LFO phase=90 degrees) delay time
Depth
Sets the Tap3 chorus depth
0...30
Level
Sets the Tap3 output level
0...30
Pan L6...L1, C, R1...R6
Sets the Tap3 stereo image
e
Tap4(270) [msec] 0...570msec
Sets the Tap4 (LFO phase=270 degrees) delay time
Depth
Sets the Tap4 chorus depth
0...30
Level
Sets the Tap4 output level
0...30
Pan L6...L1, C, R1...R6
Sets the Tap4 stereo image
f
Tap1 Feedback
Sets the Tap1 feedback amount
–100...+100
Src Off...Tempo
Selects the modulation source of Tap1 feedback amount and effect balance
Amt –100...+100
Sets the Tap1 feedback amount and modulation amount
g
Wet/Dry Dry, 1:99...99:1, Wet
Table , “Sets the balance between the effect and dry sounds,” on page 175
Amt
Table , “Sets the modulation amount of the effect bal-
ance,” on page 175
–100...+100
Left
Right
Feedback
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In -Stereo Out
+
Level
Level
Level
Level
Pan
Pan
Pan
Pan
LFO: Triangle
Tap1 Delay
Tap2 Delay
Tap3 Delay
Tap4 Delay
0 [degree]
180 [degree]
90 [degree]
270 [degree]
