204
Effects
ER/Delay
045: M.Tap Delay
(Stereo Multitap Delay)
The left and right Multitap D
elays have two taps
respectively.Changingtheroutingoffeedbackandtap
output allows you to create various patterns of com
plexeffectsou
nds.
a: Mode
You can change how the left and right delay signals are
panned by modifying the routing of the left and right delay as
shown in the figure above. You need to input different sounds
to each channel in order for this parameter to be effective.
d: Tap1 Level
This parameter sets the output level of Tap1. Setting a differ-
ent level from Tap2 will add a unique touch to a monotonous
de
lay and feedback.
046: Modul.Delay
(Stereo Modulation Delay)
Thisst ereo delayusesanLFOtosweepthedel
aytime.
The pitch also varies. You will obtain a delay sound
with swell and shimmering. You can also control the
delaytimeusingamodulationsource.
b: D-mod Modulation
When the modulation source is used for control, this parame-
ter reverses the left and right modulation direction.
e: LFO Sync, e: Src,
f: L LFO Phase [degree], f: R LFO Phase [degree]
The LFO can be reset via a modulation source.
The “Src” parameter sets the modulation source that resets
the
LFO. For example, you can assign Gate as a modulation
a
Mode Normal, Cross Feedback, Cross Pan1, Cross Pan2
Switches the left and right delay routing
b
Tap1 Time [msec]
Sets the Tap1 delay time
0.0...680.0msec
c
Tap2 Time [msec]
Sets the Tap2 delay time
0.0...680.0msec
d
Tap1 Level
Sets the Tap1 output level
0...100
e
Feedback (Tap2)
Sets the Tap2 feedback amount
–100...+100
Src Off...Tempo
Selects the modulation source of the Tap2 feedback amount
Amt –100...+100
Sets the modulation amount of the Tap2 feedback amount
f
High Damp [%]
Sets the damping amount in the high range
0...100%
Fx:043
g
Low Damp [%]
Sets the damping amount in the low range
0...100%
Fx:043
h
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
Fx:037
i
Spread –100...+100
Sets the width of the stereo image of the effect sound
Fx:043,
Src Off...Tempo
Selects the modulation source of the effect sound’s stereo image width
Amt –100...+100
Sets the modulation amount of the effect sound’s stereo image width
j
Wet/Dry Dry, 1:99...99:1, Wet
Table , “Sets the balance between the effect and dry sounds,” on page 175
Src Off...Tempo
Table , “Selects the modulation source of the effect balance,” on page 175
Amt
Table , “Sets the modulation amount of the effect bal-
ance,” on page 175
–100...+100
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp
Low Damp
High Damp
Low Damp
Delay
Delay
Feedback
Tap1 Level
Mode
Mode
(1)
(2)
(1)
(2)
Tap1=(1)
Tap2=(2)
Mode: Normal Mode: Cross Feedback Mode: Cross Pan1
Mode: Cross Pan2
a
Modulation Mode LFO, D-mod
Switches between LFO modulation control and modulation source control
b
D-mod Modulation
Reversed L/R control by modulation source
L/R:+/+, L/R:+/–
,
Src Off...Tempo
Selects the modulation source that controls delay time
Response 0...30
Sets the rate of response to the modulation source
c
LFO Waveform
Selects LFO Waveform
Triangle, Sine
LFO Shape –100...+100
Determines how much the LFO waveform is changed Fx:020
d
LFO Frequency [Hz]
Sets the LFO speed
0.02...20.00Hz
e
LFO Sync
Switches LFO reset off/on
Off, On
,
Src Off...Tempo
Selects the modulation source that resets the LFO
f
L LFO Phase [degree] –180...+180
Sets the phase obtained when the left LFO is reset
R LFO Phase [degree] –180...+180
Sets the phase obtained when the right LFO is reset
g
L Depth
Sets the depth of the left LFO modulation
0...200
R Depth
Sets the depth of the right LFO modulation
0...200
h
L Delay Time [msec]
Sets the left delay time
0.0...500.0
R Delay Time [msec]
Sets the right delay time
0.0...500.0
i
L Feedback
Sets the feedback amount of left delay
–100...+100
R Feedback
Sets the feedback amount of right delay
–100...+100
j
Wet/Dry –Wet...–1:99, Dry, 1:99...Wet
Table , “Sets the balance between the effect and dry sounds,” on page 175
Fx:010,
Src Off...Tempo
Table , “Selects the modulation source of the effect balance,” on page 175
Amt
Table , “Sets the modulation amount of the effect bal-
ance,” on page 175
–100...+100
Left
Right
Feedback
LFO Phase
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
LFO: Tri / Sine
Modulation Mode
D-mod
LFO
D
-mod
Delay
Delay
L/R: +/+ +/–
LFO Shape
Response
LFO Sync
