113
Program operating mode
Page 8 - Filter Modulation
Resonance modulation
AMS (Alternate Modulation Source)
Selects the source that will control the “Resonance”
level.See“A M S (AlternateModulationSou
rce)list”on
page123.
Intensity (AMS Intensity)
Thisparameterspecifiesthedepthanddirectionofthe
effect that “A M S (Alternate Modulation Sour
ce)” will
have on the resonance level specified by “Resonance
A”.
For example if Velocity has been sel
ected, changes in
keyboardvelocitywillaffecttheresonance.
Withpositive(+)values,there
sonancewillincreaseas
you play more strongly, and as you play more softly
the resonance will approach the levelspecifiedby the
“Resonance”setting.
Withnegative(–)values,theresonan
cewilldecreaseas
you play more strongly, and as you play more softly
the resonance will approach the levelspecifiedby the
“Resonance”setting.
Theresonancelevelisdeterminedbyaddi
ngthe“Res‐
onance”and“Intensity(AMSIntensity)”valu
es.
‐99…+99 Parametervalue.
Filter B
Frequency B (Cutoff Frequency B)
ThisparameterspecifiesthecutofffrequencyoffilterB.
Thisparameterwillbedisplayedwhen“FilterType”is
settoLowPass&HighPas
s.
00…99 Cutofffrequencyvalue.
PAGE 8 - FILTER MODULATION
These settings let you apply modulation to the cutoff
frequency (“Frequency”) of the filter for the selected
oscillatortomodifythetone.
When“FilterType”isLowPassResonance,paramete
rs
forfilterBwillnotbeeditable(greyedout).
Selected
Usethisparametertoselectanoscillatortoputinedit.
Alternatively,youcanselectoscillatorsusingtheF‐1–F‐
4buttons.
Filter keyboard tracking
Tracking Low/High
Thesesettingsspecifykeyboardtrackingforthecutoff
frequency of the filter for the selected oscillator. The
way in which the cutoff frequency is affected by the
keyboard location you play can be specified by the
“Tracking Low”, “Tracking Hi
gh”, “Ramp Low ” and
“RampHigh”parameters.
C–1…G9 L
owest/Highestnoteintherange.
Tracking Low
Keyboard tracking will apply to the range below the
specifiednotenumber.
Tracking High
Keyboard tracking will apply to the range above the
specifiednotenumber.
Ramp
Thisparameterspecifiestheangleofkeyboardtracking.
‐99…+99 Anglevalue.
Here is how cutoff frequency is affected by keyboard
location
and the Ramp setting (“ Intensity to A” and
“IntensitytoB”=+50):
Ramp Low
Ramp High
If “Intensity to A”and “Intensity toB”are set to +50,
“Ramp Low” is set to –62 and “Ramp High” is set to
+62, the angle of the change in cutoff frequency will
correspond to the keyboard location (pi tch). This
means that the oscillation that occurs when you
increasethe“ResonanceA”wil
lcorrespondtothekey‐
boardlocation.
Ifyouset“RampLow”to+43and“RampHigh”to–43
,
thecutofffrequencywillnotbeaffectedbykeyboard
location.Usethissettingwhenyoudonotwantthe
cutofffrequencytochangeforeachnote.
Tracking to A/B
These parameters specify the note numbers at which
keyboard tracking will begin to apply, and set the
“Intensity to A” and “Intensity to B” parameters to
specify the depth and direction of the change applied
tofiltersAandB.
For the range of notes between “Key Low” and “Key
High”
, the cutoff frequency will change according to
thekeyboardlocation(pitch).
‐99…+99 Parametervalue.
The effect of resonance
Low Pass
Level
Low resonance value High resonance value
Level
Frequency
High Pass
This filter cuts the low-frequency range that
lies below the cutoff frequency. By cutting
the lower overtones, it lightens the tone.
12dB/oct
Cutoff frequency
Key
Low Ramp=+99
Low Ramp=+43
Low Ramp=0
Low Ramp=–62
Low Ramp=–99
High Ramp=+99
High Ramp=+62
High Ramp=0
High Ramp=–43
High Ramp=–99
Low Key
High Key
