207
a: BPM, b: L Delay Base Note, b: Times, c: C Delay Base
Note,
c: Times, d: R Delay Base Note, d: Times
The delay time is the length of the note obtained by multiply-
ing the “Base Note” parameter by the Times value, in relation
to the tempo specified
by the “BPM” parameter (or the MIDI
Clock tempo if “BPM” is set to MIDI).
050: BPM Delay
(Stereo BPM Delay)
This stereo delay enables you to set the delay time to
matchthesongtempo.
Note:Wi
thextremevalues,thesyncmaybelos
t.
051: Seq. Delay
(Sequential Delay)
This four‐tapdelay enables you to select a
tempo and
rhythmpatterntosetupeachtap.
a: BPM, b: Rhythm Pattern
With the tempo specified by the “BPM” parameter (or the
MIDI Clock tempo if “BPM” is set to MIDI), th
e length of one
beat equals the feedback delay time, and the interval
between taps becomes equal. Selecting a rhythm pattern will
automatically turn the tap outputs on and off. When “BPM” is
set to MIDI, the lower limit of the “BPM” is 44.
a
BPM MIDI, 40...240
Selects MIDI Clock and assigns tempo Fx:049,
R > ----, OVER!!
Display the error message if the right channel delay time exceeds the upper
limit
b
L Delay Base Note
Selects the type of notes to specify the left channel delay time
Fx:049,
Times x1...x16
Sets the number of notes to specify the left channel delay time
Fx:049
Adjust [%]
Fine-adjust the left channel delay time
–2.50...+2.50%
c
R Delay Base Note
Selects the type of notes to specify the right channel delay time
Fx:049,
Times x1...x16
Sets the number of notes to specify the right channel delay time
Fx:049
Adjust [%]
Fine-adjust the right channel delay time
–2.50...+2.50%
d
L Feedback
Sets the feedback amount for the left channel
–100...+100
Src Off...Tempo
Selects the modulation source of feedback amount
Amt L –100...+100
Sets the modulation amount of the left channel feedback
e
R Feedback
Sets the feedback amount for the right channel
–100...+100
Amt R –100...+100
Sets the modulation amount of the right channel feedback
f
High Damp [%]
Sets the damping amount in the high range
0...100%
Fx:043
g
Low Damp [%]
Sets the damping amount in the low range
0...100%
Fx:043
h
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
Fx:037
i
Wet/Dry Dry, 1:99...99:1, Wet
Tab le , “Sets the balance between the effect and dry sounds,” on page 175
Src Off...Tempo
Tab le , “Selects the modulation source of the effect balance,” on page 175
Amt
Tab le , “Sets the modulation amount of the effect bal-
ance,” on page 175
–100...+100
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp
Low Damp
Tempo
BPM
BPM
Base Note x Times
Base Note x Times
Adjust [%]
Adjust [%]
Delay
Delay
a
BPM
Selects MIDI Clock and assigns tempo
MIDI, 44...240
,
b
Rhythm Pattern
Selects a rhythm pattern
– – – ... 3
,
c
Tap1 Pan
Sets the panning of Tap1
L, 1...99, R
Tap2 Pan
Sets the panning of Tap2
L, 1...99, R
Tap3 Pan
Sets the panning of Tap3
L, 1...99, R
Tap4 Pan
Sets the panning of Tap4
L, 1...99, R
d
Feedback
Sets the feedback amount
–100...+100
Src Off...Tempo
Selects the modulation source of feedback amount
Amt
Sets the modulation amount of the feedback
–100...+100
e
High Damp [%]
Sets the damping amount in the high range
0...100%
Fx:043
Low Damp [%]
Sets the damping amount in the low range
0...100%
Fx:043
f
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
Fx:037
g
Wet/Dry Dry, 1:99...99:1, Wet
Table , “Sets the balance between the effect and dry sounds,” on page 175
Src Off...Tempo
Table , “Selects the modulation source of the effect balance,” on page 175
Amt
Table , “Sets the modulation amount of the effect bal-
ance,” on page 175
–100...+100
Delay
Left
Right
Feedback
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In -Stereo Out
Input Level D-mod
High Damp Low Damp
Input Level D-mod
+
Tempo
BPM
BPM
Rythm Pattern
Pan
