Comfort Control Unit
126
Pos: 21.15.10 / BA/Info-Center/L adewagen/H auptmenüs/Ha uptmenü 4 Ser vice/Einstell werte Sensor Achse gesperrt @ 0\mod_1200911 165306_78.d oc @ 47775
Setting values:
The minimum and maximum setting values with the sensor alive (metal in front of the sensor)
are shown in the upper part of the bar display. The current setting value (actual value) is
displayed under the bar display.
The distance from the sensor to the metal must be adjusted so that in the alive state the bar is
in the upper mark. Next check whether the bar is in non-alive state in the lower marked area.
Pressure sensor diagnostics
Possible sensors (depending on how the machine is equipped)
State:
No. Sensor icon Description
B1
Axle locked
State:
Axle locked
Axle released
