Comfort Control Unit
86
Pos: 21.7.12 /B A/Info-Center/La dewagen/Soft key Ladebetri eb rechte Spalt en S3 Knickdeich sel heben/s enken @ 0\mod _1200646552 834_78.doc @ 4 6104
ZX000011
A
Figure 50:
Raise/lower offset drawbar
Raise offset drawbar
Press the key for softkey . The arrow (A) indicates that the function is executed.
Lower offset drawbar
Press the key for softkey . The arrow (A) indicates that the function is executed.
Pos: 21.7.13 /B A/Info-Center/La dewagen/Soft key Ladebetri eb rechte Spalt en S4 Kratzbo denvorlauf @ 0\mod_1200647 575084_78.doc @ 46125
ZX000012
A
Figure 51:
Actuate floor conveyor supply
Press the key for softkey . The symbol appears in reverse video and the floor
conveyor continues running as long as the key is pressed.
The arrow (A) indicates that the function is executed.
