Comfort Control Unit
85
Pos: 21.7.10 /B A/Info-Center/La dewagen/Soft key Ladebetri eb rechte Spalt en S2 Messer ei n/aus @ 0\ mod_1200646042 771_78.doc @ 46084
ZX000010
A
C
B
Figure 49:
Swinging blades out/in
The activated mode will be indicated on the display (A). If the blades are in the maintenance
position, the (C) symbol will be displayed.
Swinging blades in
Press the
key for softkey
. The arrow (B) indicates that the function is executed.
Swinging blades out
Press the
key for softkey
. The arrow (B) indicates that the function is executed.
Blades in maintenance position
If the blades are swung out, press the
key for softkey
again. The (C) symbol for
blades in maintenance position appears.
