Comfort Control Unit
84
Pos: 21.7.8 /BA/ Info-Center/Lad ewagen/Softke y Ladebetrie b rechte Spalte n S1 Pick-up @ 0\mod_120064 5557271_78.d oc @ 46065
Softkeys
The two right columns contain the following softkeys:
ZX000009
A
B
Figure. 48
Raise and lower pickup/floating position
The activated mode appears in display (A).
Pick-up not in float position
Pick-up in float position
Raise pick-up
Press the
key for softkey
. The arrow (B) indicates that the function is executed.
Lowering pick-up/floating position
Press the
key for softkey
.
The arrow (B) indicates that the function is executed.
