Larson Davis 824 User Manual

9/29/09 A-29
Group Read Programming
The group command permits the
programming of a user-defined
macro with up to eight (8) Read
variables. The macro is executed
with the G0 or O[ther] 3 commands
which returns the list of defined read
variables.
Use the following command syntax
to program each desired read
variable and its position in the
macro.
O 8 AUD, FFT Read THD data: Fund. Frequency, Fund Level, THD+n,
2nd, 3rd, 4th, 5th and above.
nnnnnn, nnn.n, n.nn,n.nn,n.nn,n.nn
O 9 AUD, FFT Read Fund. Frequency and Fund. Level
nnnnnn, nnn.n
Code Description Response
Syntax Response
G[roup]n, var_no <cr><lf>
Example: G1, 4 <cr> assigns the current SPL to the first group option
Example: G2, 15 <cr> assigns Lmin to the second option
Example: G3, 19 <cr> assigns Lmax to the third option
Example: G4, 0 <cr> terminates group command programming
