A-66 824 Reference Manual 9/29/09
Calibration History Variables (LOG)
Brackets in the syntax indicate
optional characters.
L[og]var_nolog_var
Example: L1 Run/Stop number
L 1 Run/Stop Number nnnnn
L 2 Run/Stop Type (RUN/STOP/CONT/PAUSE/MARK)
L 3 Cause (TIMER/KEY/A:D-n/HALT/INTV/
BATT)
L 4 Day, Date and Time ddd ddmmmyyyy hh:mm:ss
L 101 Run-Log Macro Variables L1-L5 Macro
Syntax Response
C[alibration]var_no cal_var
Example: C1 114.0 (checked level)
C 1 Checked Level nnn.n
C 2 Day, Date and Time ddd ddmmmyyyy hh:mm:ss
C 3 Calibration Mode [Manual/Auto]
C 4 Cal Status [OK/Bad]
C 101 Cal Variables 1-4 Macro
