3-12 824 Reference Manual 9/29/09
c Check Key
The c key allows you to choose an item from a menu or to
confirm the entry of a setting.
Pressing
c in many displays will bring up a menu from
which you can make changes to settings appropriate to that
display.
V View Key
The display of data on screen of the System 824 is controlled
by the
V VIEW key. Each instrument type (e.g. SSA, ISM,
or LOG) has its own set of available data displays which are
selected using this key. When you press the
V key, a menu
containing the available data displays will appear. The fol-
lowing example is a View menu for the SSA instrument:
The
uordkeys and c key allow you to select the
desired display. While viewing data, often more than one
display screen is available. You can use the
l and r
arrow keys to move from one screen to another.
The data displays available under the
V key depend on the
instrument type used to measure the data. These will be
described in more detail in later chapters dedicated specifi-
cally to each instrument type.
