4-12 824 Reference Manual 9/29/09
The Data Files check menu includes the following:
Selecting and Modifying Instrument Definitions (IDs)
As explained in the section "System 824 Setups or
Instrument Definitions" on page 2-1, the way to prepare the
System 824 for a measurement is to select an existing Setup
or Instrument Definition (ID) from the list which appears on
the display after pressing the Setup Key
S and either use it
as-is or modify it to suit the requirements of the
measurement to be performed. In this section, we will
explain in general how an ID is modified and stored using
the Setup Menu of the System 824. More detailed
descriptions for specific Instrument Types (e.g. ISM, LOG,
or SSA) will be provided in later chapters. When a PC is
available, the 824 Utility software is a very powerful tool for
creating and storing new IDs and uploading them to the
System 824 for use.
Menu Items Description
Recall Data Recall the stored data file’s measure-
ment.
Beginning Displays the Data File Summary of
the first stored data file.
Ending Displays the Data File Summary of
the last stored data file.
Find Allows you to find and display a Data
File Summary by entering its associ-
ated Data File Number.
Purge All Data
Files
Gives you the option to completely
remove from memory all stored data
files.
