9/29/09 Overview 2-11
also be changed from the Setup Menu, as described later in
this manual or it can be changed here.
Step 1 To change the gain, Use the
uordkeys to
highlight the Gain, as shown below
.
The gain shifts the dynamic range up
or down. See page 5-3.
Step 2 Use the
rorlarrow keys to change the input
gain.
Views
For each instrument type (e.g. ISM, LOG or SSA), a unique
set of data displays or VIEWS are available.
Selecting a VIEW
There are eight different VIEW choices available in the SSA
instrument.
Step 1 To display the set of available data presentations,
or VIEWS, press the
V View key (use thed
and
u keys to scroll through the entire range of
choices).
