Larson Davis 824 User Manual

A-44 824 Reference Manual 9/29/09
Histogram Reports
The RMS, Peak and UWPk
histogram reports have been
implemented with this revision. The
unformatted reports have also been
developed and the format is the level
of the first bin followed by the
number of samples in each bin (in
hex, 0-9 & a–F). There are 1024
RMS bins and 128 Peak and UWPk
bins, this corresponds to 1/8th dB
resolution for RMS and 1dB
resolution for the peak tables.
S104 LOG SPL HISTOGRAM TABLE (x)
S105 LOG SPL HISTOGRAM TABLE LOW
VA L U E
(n)
S106 LOG SPL HISTOGRAM TABLE HI
VA L U E
(n)
S107 LOG SPL HISTOGRAM TABLE RESO-
LUTION
(x)
S108 LOG PEAK-II HISTOGRAM TABLE (x)
S109 LOG PEAK-II HISTOGRAM TABLE
LOW VALUE
(n)
S110 LOG PEAK-II HISTOGRAM TABLE HI
VA L U E
(n)
S111 LOG PEAK-II HISTOGRAM TABLE
RESOL
(x)
S112 LOG PEAK-I HISTOGRAM TABLE (x)
S113 LOG PEAK-I HISTOGRAM TABLE LOW
VA L U E
(n)
S114 LOG PEAK-I HISTOGRAM TABLE HI
VA L U E
(n)
