Larson Davis 824 User Manual

9/29/09 C-49
Power/Current Draw of 824 Using External Power
Off Stopped LOG
Running with
backlight OFF
LOG
Running with
backlight ON
SSA
Running with
backlight OFF
SSA
Running with
backlight ON
Power
Not Charging
0.012
W
0.96 W 1.28 W 1.73 W 1.72 W 2.21 W
Power
Charging
N/A 2.25 W 2.53 W 3.05 W 3.00 W 3.50 W
15 V 0.9 mA 65 mA 85 mA 118 mA 116 mA 150 mA
12 V 1.1 mA 80 mA 107 mA 144 mA 143 mA 184 mA
Current
Not Charging
9 V 1.3 mA 105 mA 137 mA 191 mA 189 mA 243 mA
15 V N/A 155 mA 170 mA 204 mA 202 mA 236 mA
12 V N/A 187 mA 211 mA 254 mA 248 mA 291 mA
Current
Charging
9 V N/A 248 mA 278 mA 339 mA 338 mA 402 mA
