7-78 824 Reference Manual 9/29/09
Following is a chart of the “Excd Time History” check menu
with a description of each menu item:
Daily History Check Menu The Daily History display has two different check menus,
one for the Daily data and one for the Hourly data.
When viewing the Daily History the following menu
appears after pressing the Check
c key:
Following is a chart of the “Daily History” check menu with
a description of each menu item:
Menu Items Purpose
Excd Data View Excd-a and Excd-b displays
Locate Locates a specific Exceedance
record
Settings Modifies the Exceedance settings
Graph Adjusts the scaling of the Excd
Time History graph
Menu Items Purpose
Hourly Data Displays hourly data
First Displays the first hourly record
Last Displays the last hourly record
Find Displays a specific record
Settings Modifies the Daily History settings
