Larson Davis 824 - RTA Settings Commands

9/29/09 A-51
RTA Settings Commands
S53 RTA Filter Bandwidth [1/1 | 1/3]
S54 RTA Detector [Lin | Exp] Time Weighting
S55 RTA Linear Detector Time (ss.ssss) seconds
S56 RTA Exponential Detector Time [1/64 | 1/32
| 1/16 | ... 32 | 64]
S57 RTA Exponential Detector Sample Rate [1/2
| 1/8]
S58 RTA Auto-Store Records [No | Yes]
S59 RTA Event By-Time Pretrigger Samples
(nnn)
S60 RTA Event Triggering Enable [No | Yes]
S61 RTA Trigger Source Level [12.5 | 16.0 |... |
16.0K | 20.0K | Flat] Hz
S62 RTA Store By-Time Samples of Event [No |
Yes]
S63 RTA Arm Mode [... | L < | L = | Input | Time |
Count]
S64 RTA Arm Level (nnn.n) dB
S65 RTA Arm Time (ss.ssss) Sec (for Level and
Time Arm Mode Conditions)
S66 RTA Arm Samples (nnnnn)
S67 RTA Arm Logic Input TRUE Level [Low |
High]
S68 RTA Trigger Mode [... | L < | L = | Input |
Time | Count]
S69 RTA Trigger Level (nnn.n) dB
S70 RTA Trigger Time (ss.ssss) Sec
