Larson Davis 824 User Manual

11-14 824 Reference Manual 9/29/09
Then Settings Menu
End Then
After the measurement ends, the 824 may do the following:
• Stop - The measurement ends.
• Repeat - The measurement repeats when the Arm and
Trigger settings have been satisfied. A new Autostore
record is created for each repeated measurement.
Repeat Averaging requires the End
Mode to be set to Time or Count so
that all records are the same length.
• Average - The measurement repeats (like repeat above)
except that the spectra are averaged with the preceding
spectra.
Repeat Count
Allows the user to select how many times the measurement
will repeat when the “End Then” setting is set to Repeat.
• 0 - 255
Average Count
This is the number of times the measurement is repeated and
averaged when the “End Then” setting is set to Average.
•0 - 9
Trigger Settings Menu (continued)
Run on Input
When set to Yes the instrument will run when the logic input
line changes to the “Run Logic In” state.
•No
•Yes
Run Logic In
•Low
