Lenze i950

Address Name / seng range / [default seng] Info
0x2870:003 SafetyInterface: SafetyInterface IOState
•
R
ead only
Bit 0 SD-In1
Bit 1 SD-In2
Bit 2 SD-In3
Bit 3 SD-In4
Bit 4 AIS SD-In
Bit 5 AIE SD-In
Bit 6 IRS SD-In
Bit 7 IRL SD-In
Bit 8 AIS S-Bus
Bit 9 AIE S-Bus
Bit 10 SHOM_Start S bus
Bit 11 SHOM_Load S bus
Bit 12 SD-Out1
Bit 16 SD-In1 channel A
Bit 17 SD-In1 channel B
Bit 18 SD-In2 channel A
Bit 19 SD-In2 channel B
Bit 20 SD-In3 channel A
Bit 21 SD-In3 channel B
Bit 22 SD-In4 channel A
Bit 23 SD-In4 channel B
Bit 24 SD-Out1 channel A
Bit 25 SD-Out1 channel B
0x2871:001 SafetyInterface bits: STO acve
•
R
ead only
0x2871:002 SafetyInterface bits: SS1 acve
•
Read only
0x2871:003 SafetyInterface bits: SS2 acve
•
Read only
0x2871:004 SafetyInterface bits: SOS acve
•
Read only
0x2871:005 SafetyInterface bits: SLS1 acve
•
Read only
0x2871:006 SafetyInterface bits: SLS2 acve
•
R
ead only
0x2871:007 SafetyInterface bits: SLS3 acve
•
Read only
0x2871:008 SafetyInterface bits: SLS4 acve
•
Read only
0x2871:009 SafetyInterface bits: SDIpos acve
•
Read only
0x2871:010 SafetyInterface bits: SDIneg acve
•
Read only
0x2871:011 SafetyInterface bits: SLI acve
•
Read only
0x2871:012 SafetyInterface bits: SSE acve
•
Read only
0x2871:013 SafetyInterface bits: ES acve
•
Read only
0x2871:014 SafetyInterface bits: OMS acve
•
R
ead only
0x2871:015 SafetyInterface bits: RMS acve
•
Read only
0x2871:016 SafetyInterface bits: SBC acve
•
Read only
Safety funcons
Connecon to the applicaons
Status signals
447
