Gocator Line Profile Sensors: User Manual
Gocator Device Files • 490
Element Type Description
DynamicThreshold.used Bool Determines if the setting’s value is currently used.
DynamicThreshold.value 32s Value in use by the sensor, useful for determining value when
used is false.
DynamicThreshold.min 32s Minimum value.
DynamicThreshold.max 32s Maximum value.
SensitivityCompensationEnabled Bool Sensitivity compensation toggle. Used in determining analog and
digital gain, along with exposure scale.
SensitivityCompensationEnabled.used Bool Determines if the setting’s value is currently used.
SensitivityCompensationEnabled.value Bool Value in use by the sensor, useful for determining value when
used is false.
GammaType 32s Gamma type.
GammaType used Bool Determines if the setting’s value is currently used.
GammaType value 32s Value in use by the sensor. Useful for determining value when
used is false.
SpotContinuitySorting Section
See SpotContinuitySorting Child Elements below.
SurfaceEncoding 32s Surface encoding type:
0 – Standard
1 – Interreflection (advanced use only)
SurfaceEncoding.used Bool Determines if the setting’s value is currently used.
SurfaceEncoding.value Bool Value in use by the sensor, useful for determining value when
used is false.
SurfacePhaseFilter 32s
Surface phase filter (correction type)
0 – None
1 – Reflective
2 - Translucent
SurfacePhaseFilter.used Bool Determines if the setting’s value is currently used.
SurfacePhaseFilter.value Bool Value in use by the sensor, useful for determining value when
used is false.
Element Type Description
MinimumSegmentSize 32u Smallest continuous segment considered in continuity sorting.
SearchWindow/X 32u X component of continuity sorting search window size.
SearchWindow/Y 32u Y component of continuity sorting search window size.
SpotContinuitySorting Child Elements
IndependentExposures settings are only supported by Gocator 3000 series sensors.
