4.2.2 Windrower Operating Symbols
These symbols, found on the console, indicate that the button or indicator on which the symbol is found pertains to a
particular windrower function.
Figure 4.2: Windrower Operating Symbols
1026690
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
S
T
U
V
W
A - Turn Signals B - Hazard Warning Lights C - Forward
D - Neutral E - Reverse F - Headlights Low Beam
G - Headlights High Beam H - Work Light J - Lighter
K - Fresh Air L - Blower M - Windshield Wiper
N - Seat Height Up P - Seat Height Down Q - Seat Fore and Aft
R - Seat Fore Aft Isolator S - Seat Back Fore and Aft T - Seat Ride Damping
U - Cab Temperature Control V - Air Conditioning W - Recirculate
