5.5.2 Lubrication Points
These are the points on the windrower which will need to receive regular lubrication. Refer to the Maintenance Schedule
to learn how often to apply grease to these areas.
1026433
E
B
A
C
D
A
E
Figure 5.15: Lubrication Points
A - Forked Caster Wheel Bearing (Two Places) (Outer – Both Wheels)
B - Top-Link (Two Places) (Both Sides)
C - Lubrication Decal (MD #183411)
D - Caster Pivot (Both Sides)
E - Forked/Formed Caster Wheel Bearing (Two Places) (Inner – Both Wheels) (50 Hrs/250 Hrs)
