MacDon M155 2022 - Cleaning Return Air Cleaner;Filter

215676 337 Revision A
1000131
A
B
Figure 5.34: Return Air Filter
2. Separate filter (B) from cover (A).
3. Clean or replace the filter. If you intend to clean the filter,
refer to Cleaning Return Air Cleaner/Filter, page 337.
4. Assemble filter (B) and cover (A). Position the assembly
over the air return opening on the wall of the cab.
1000132
A
B
Figure 5.35: Return Air Filter
5. Secure filter assembly (B) to the cab wall with knobs (A).
Cleaning Return Air Cleaner/Filter
If the filter is in good condition, it may be cleaned instead of replaced.
1020943
A
Figure 5.36: Return Air Filter
1. Mix a solution of warm water and detergent in a suitable
container. Soak filter (A) in the solution for a few minutes.
2. Agitate the solution to flush dirt out of the filter.
3. Rinse filter (A) with clean water. Dry the filter using
compressed air.
4. Inspect filter (A) for damage, separation, or holes. Replace
the filter if it is damaged.
MAINTENANCE AND SERVICING
