Display (Lower or Upper Line)
Description
ENGINE TEMP ### °F
ENGINE TEMP ### °C (if metric)
Engine coolant temperature
SCROLL
SUB-MENU (lower line only)
#### KNIFE SPEED
##.# AUGER SPEED
##.## REEL RPM
##.# HEADER HEIGHT
Displays sub-menu after 2–3 seconds. Press SELECT to cancel. Scroll through
sub-menu display with CDM switch
Knife speed is optional
Reel rpm is optional
Cab-Forward, Engine Running, Header Engaged, Draper Header Attached, Index Switch OFF
These are the messages which can appear in the cab display module (CDM) when the windrower is in cab-forward mode,
the engine is running, the attached draper header is engaged, and the header index switch is set to the OFF state.
Display (Lower or Upper Line)
Description
#####.# ENGINE HRS
Displays the total engine operating time
#####.# UNIT HRS
Displays the windrower’s total operating time
#####.# HEADER HRS
Displays the header’s total operating time
##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)
Displays the actual cutting rate in acres or hectares per hour
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Displays the total area cut since the last reset was performed. To reset this
value: set the CDM to display SUB ACRES on the lower line, then hold down
the PROGRAM switch for five to seven seconds until the display resets
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Displays the total area cut by the machine
##.## REEL MPH
##.## REEL KPH (if metric)
##.## REEL SENSOR (flashing)
Displays the reel’s peripheral speed in miles per hour or kilometers per
hour.
This message appears if the reel sensor is disabled. The messages MPH /
KPH and SENSOR appear alternately at one-second intervals
##.# DRAPER SPEED
Displays the speed of the draper (0.0–11.0)
#### KNIFE SPEED
#### KNIFE SENSOR
Displays the knife speed in strokes per minute
This message appears if the knife speed sensor is disabled. The messages
SPEED and SENSOR appear alternately at one-second intervals
##.# HEADER HEIGHT
##.# HEADER SENSOR
Displays the distance setting (00.0–10.0) between the cutterbar and the
ground
This message appears if the header height sensor is disabled. The messages
HEIGHT and SENSOR appear alternately at one-second intervals
##.# HEADER ANGLE
##.# HEADER SENSOR
Displays the angle setting (00.0–10.0) of the header relative to the ground
This message appears if the header angle sensor is disabled. The messages
ANGLE and SENSOR appear alternately at one-second intervals
##.# L FLOAT R ##.#
FLOAT SENS DISABLED
Displays the left and right float settings (0.0–10.0)
This message appears if the float sensor is disabled
### °C or F HYD OIL TEMP
### °C or F HYD SENSOR
Displays the temperature of the hydraulic oil
This message appears if the temperature sensor is disabled. The messages
TEMP and SENSOR appear alternately at one-second intervals
OPERATOR’S STATION
