8.2.3 Lubricants, Fluids, and System Capacities
Refer to the table below for information on the appropriate lubricants and fluids for the windrower, and for the capacity of
each system. Follow the procedures for filling each system provided in this manual.
WARNING
To avoid injury or death, do NOT allow ANY machine fluids to enter the body.
Table 8.16 Windrower System Capacities
Lubricant/Fluid
Location
Description Capacity
Grease
As required unless
otherwise specified
SAE multi-purpose high temperature
extreme pressure (EP2) performance with
1% maximum molybdenum disulphide
(NLGI Grade 2); lithium base
—
Diesel fuel
Fuel tank
Diesel Grade No. 2, or Diesel Grade No. 1
and 2 mix
57
; refer to 8.2.2 Fuel
Specifications, page 476 for more
information
378 L
(97 U.S. gal)
Hydraulic oil Hydraulic reservoir
SAE 15W-40 compliant with SAE specs for
API class SJ and CH-4 engine oil.
65 L
(17.2 U.S. gal)
Gear lubricant Gearbox
SAE 80W-140
58
, API service class GL-5 fully
synthetic gear lubricant (SAE J2360
preferred)
2.1 L
(2.2 U.S. qt.)
Gear lubricant Wheel drive
59
SAE 75W-90, API service class GL-5 fully
synthetic gear lubricant (SAE J2360
preferred)
1.4 L
(1.5 U.S. qt.)
Coolant
Engine cooling
system
ASTM D-6210 and CES-14603, Peak Final
Charge Global
™
, Fleetguard
®
ES Compleat
™
OAT; refer to notes following this table
27.5 L
(7.3 U.S. gal)
60
Engine oil Engine oil pan
SAE 15W-40 compliant with SAE specs for
API class SJ and CH-4 engine oil
11 L
(11.6 U.S. qt.)
Air conditioning
refrigerant
61
Air conditioning
system
R134A
2.27 kg (5 lb.)
Air conditioning
refrigerant oil
62
Air conditioning
system total capacity
PAG SP-15
240 cc (8.1 fl. oz.)
REFERENCE
57. Optional when operating temperature is below 0°C (32°F).
58. SAE 75W-140 may be substituted for SAE 80W-140 if necessary.
59. SAE 85W-140 API Service Class GL-5. Extreme Pressure Gear Lubricant is used before initial change.
60. Equal parts with high quality, soft, deionized or distilled water as recommended by Supplier.
61. For prior models that have not upgraded to 2.27 kg (5 lb.) of refrigerant order Kit MD #183180, which includes decal
to advise of systems 2.27 kg (5 lb.) charge requirement, refer to Service Bulletin 1254.
62. New compressor (MD #183515) comes filled. If installing on 2014 and prior models, refer to Service Bulletin 1254.
