Display (Lower or Upper Line)
Description
##.# SWATH COMPR HT
SWATH CO SENSOR
Displays the swath compressor’s height setting(00.0–10.0); fully raised is
0
This message appears if the swath compressor height sensor is disabled
SCROLL
SUB-MENU (lower line only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■| ####
Displays the sub-menu after two to three seconds. Press SELECT to exit
the sub-menu. Use the CDM switch to scroll through the sub-menu
options
Cab-Forward, Engine Running, Header Engaged, Auger Header Attached, Index Switch ON
These are the messages which can appear in the cab display module (CDM) when the windrower is in cab-forward mode,
the engine is running, the attached auger header is engaged, and the header index switch is set to the ON state.
Display (Lower or Upper Line)
Description
#####.# ENGINE HRS
Displays the total engine operating time
#####.# UNIT HRS
Displays the windrower’s total operating time
#####.# HEADER HRS
Displays the header’s total operating time
##.# ACRES/HOUR
##.# HECTARES/HOUR (if metric)
Displays the actual cutting rate in acres or hectares per hour
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Displays the total area cut since the last reset was performed. To reset this
value: set the CDM to display SUB ACRES on the lower line, then hold down the
PROGRAM switch for five to seven seconds until the display resets
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Displays the total area cut by the machine
##.## ##.# REEL IND.
##.## REEL SENSOR
Displays the reel’s indexed speed in rpm and the windrower’s ground speed in
mph or km/h
This message appears if the reel sensor is disabled. The messages IND and
SENSOR appear alternately at one-second intervals
##.# AUGER SPEED
##.# AUGER SENSOR
Displays the auger’s rotational speed (4.7–9.9)
This message appears if the auger speed sensor is disabled. The messages SPEED
and SENSOR appear alternately at one-second intervals
#### KNIFE SPEED
#### KNIFE SENSOR
Displays the knife speed in strokes per minute
This message appears if the knife speed sensor is disabled. The messages SPEED
and SENSOR appear alternately at one-second intervals
##.# HEADER HEIGHT
##.# HEADER SENSOR
Displays the distance setting (00.0–10.0) between the cutterbar and the ground
This message appears if the header height sensor is disabled. The messages
HEIGHT and SENSOR appear alternately at one-second intervals
##.# HEADER ANGLE
##.# TILT SENSOR
Displays the angle setting (00.0–10.0) of the header relative to the ground
This message appears if the header angle sensor is disabled. The messages TILT
and SENSOR appear alternately at one-second intervals
##.# L FLOAT R ##.#
FLOAT SENS DISABLED
Displays the left and right float settings (0.0–10.0)
This message appears if the float sensor is disabled
